HRC45 3D Solid Carbide Drill Bit Metal 6mm Drilling Hardened Steel With Carbide

Ask Lasest Price
Brand Name :	BABOS
Model Number :	BBSTD3D45060
Price :	Negotiable
Payment Terms :	L/C, D/A, D/P, T/T, Western Union
Supply Ability :	10,000PCS per month
Delivery Time :	6-8 Weeks

Add to Cart

Product Details
Company Profile

HRC45 3D Solid Carbide Drill Bit Metal 6mm Drilling Hardened Steel With Carbide

HRC45 3D Solid Carbide Twist Drill For Metal 6mm28mm6mm With 66mm Overal Length

Product Description:

HRC45 3D Solid Carbide Twist Drill is a high-performance drilling tool known for its versatility and precision and used for gray cast iron, ductile iron, stainless steel,alloy steel, and other common materials processing.

Features:

Product Name:HRC45 3D Solid Carbide Twist Drill
Material: Tungsten Carbide
Application/Usage: Metal drilling
Applicable Materials: gray cast iron, ductile iron, stainless steel,alloy steel, and other common materials

Technical Parameters:

Product Material	Tungsten Carbide
Flute Number	2
Coating/Finish Type	AITiN
Tolerance	0.000mm~-0.050mm
Machine Type	CNC machines
Customize	Available
OEM	Available
Sample Order	Accepted

Product Specifications:

HRC45 Solid Carbide Twist Drill(3D)
HRC 45°:Raw Material: Use YG10X with 10% Co content and 0.8um grain size；
Standard Length					Coating:AItiN HRC 45°	Standard Length					Coating:AItiN HRC 45°
Standard Length					Coating:AItiN HRC 45°	Standard Length					Coating:AItiN HRC 45°
Cut Dia.	Cut Length.	Shank Dia.	Overal Length.	Flutes	Order No.	Cut Dia.	Cut Length.	Shank Dia.	Overal Length.	Flutes	Order No.
D(mm)	Lc(mm)	d(mm)	L(mm)	Flutes	Order No.	D(mm)	Lc(mm)	d(mm)	L(mm)	Flutes	Order No.
1	12	3	42	2	BBSTD3D45010	10.1	51	11	95	2	BBSTD3D45101
1.1				2	BBSTD3D45011	10.2				2	BBSTD3D45102
1.2				2	BBSTD3D45012	10.3				2	BBSTD3D45103
1.3				2	BBSTD3D45013	10.4				2	BBSTD3D45104
1.4				2	BBSTD3D45014	10.5				2	BBSTD3D45105
1.5				2	BBSTD3D45015	10.6				2	BBSTD3D45106
1.6				2	BBSTD3D45016	10.7				2	BBSTD3D45107
1.7				2	BBSTD3D45017	10.8				2	BBSTD3D45108
1.8				2	BBSTD3D45018	10.9				2	BBSTD3D45109
1.9				2	BBSTD3D45019	11				2	BBSTD3D45110
2				2	BBSTD3D45020	11.1	54	12	102	2	BBSTD3D45111
2.1	14	3	50	2	BBSTD3D45021	11.2				2	BBSTD3D45112
2.2				2	BBSTD3D45022	11.3				2	BBSTD3D45113
2.3				2	BBSTD3D45023	11.4				2	BBSTD3D45114
2.4				2	BBSTD3D45024	11.5				2	BBSTD3D45115
2.5				2	BBSTD3D45025	11.6				2	BBSTD3D45116
2.6				2	BBSTD3D45026	11.7				2	BBSTD3D45117
2.7				2	BBSTD3D45027	11.8				2	BBSTD3D45118
2.8				2	BBSTD3D45028	11.9				2	BBSTD3D45119
2.9				2	BBSTD3D45029	12				2	BBSTD3D45120
3				2	BBSTD3D45030	12.1	57	13	102	2	BBSTD3D45121
3.1	20	4	60	2	BBSTD3D45031	12.2				2	BBSTD3D45122
3.2				2	BBSTD3D45032	12.3				2	BBSTD3D45123
3.3				2	BBSTD3D45033	12.4				2	BBSTD3D45124
3.4				2	BBSTD3D45034	12.5				2	BBSTD3D45125
3.5				2	BBSTD3D45035	12.6				2	BBSTD3D45126
3.6				2	BBSTD3D45036	12.7				2	BBSTD3D45127
3.7				2	BBSTD3D45037	12.8				2	BBSTD3D45128
3.8				2	BBSTD3D45038	12.9				2	BBSTD3D45129
3.9				2	BBSTD3D45039	13				2	BBSTD3D45130
4				2	BBSTD3D45040	13.1	60	14	107	2	BBSTD3D45131
4.1	24	5	62	2	BBSTD3D45041	13.2				2	BBSTD3D45132
4.2				2	BBSTD3D45042	13.3				2	BBSTD3D45133
4.3				2	BBSTD3D45043	13.4				2	BBSTD3D45134
4.4				2	BBSTD3D45044	13.5				2	BBSTD3D45135
4.5				2	BBSTD3D45045	13.6				2	BBSTD3D45136
4.6				2	BBSTD3D45046	13.7				2	BBSTD3D45137
4.7				2	BBSTD3D45047	13.8				2	BBSTD3D45138
4.8				2	BBSTD3D45048	13.9				2	BBSTD3D45139
4.9				2	BBSTD3D45049	14				2	BBSTD3D45140
5				2	BBSTD3D45050	14.1	62	15	111	2	BBSTD3D45141
5.1	28	6	66	2	BBSTD3D45051	14.2				2	BBSTD3D45142
5.2				2	BBSTD3D45052	14.3				2	BBSTD3D45143
5.3				2	BBSTD3D45053	14.4				2	BBSTD3D45144
5.4				2	BBSTD3D45054	14.5				2	BBSTD3D45145
5.5				2	BBSTD3D45055	14.6				2	BBSTD3D45146
5.6				2	BBSTD3D45056	14.7				2	BBSTD3D45147
5.7				2	BBSTD3D45057	14.8				2	BBSTD3D45148
5.8				2	BBSTD3D45058	14.9				2	BBSTD3D45149
5.9				2	BBSTD3D45059	15				2	BBSTD3D45150
6				2	BBSTD3D45060	15.1	64	16	115	2	BBSTD3D45151
6.1	34	7	74	2	BBSTD3D45061	15.2				2	BBSTD3D45152
6.2				2	BBSTD3D45062	15.3				2	BBSTD3D45153
6.3				2	BBSTD3D45063	15.4				2	BBSTD3D45154
6.4				2	BBSTD3D45064	15.5				2	BBSTD3D45155
6.5				2	BBSTD3D45065	15.6				2	BBSTD3D45156
6.6				2	BBSTD3D45066	15.7				2	BBSTD3D45157
6.7				2	BBSTD3D45067	15.8				2	BBSTD3D45158
6.8				2	BBSTD3D45068	15.9				2	BBSTD3D45159
6.9				2	BBSTD3D45069	16				2	BBSTD3D45160
7				2	BBSTD3D45070	16.1	66	17	119	2	BBSTD3D45161
7.1	40	8	79	2	BBSTD3D45071	16.2				2	BBSTD3D45162
7.2				2	BBSTD3D45072	16.3				2	BBSTD3D45163
7.3				2	BBSTD3D45073	16.4				2	BBSTD3D45164
7.4				2	BBSTD3D45074	16.5				2	BBSTD3D45165
7.5				2	BBSTD3D45075	16.6				2	BBSTD3D45166
7.6				2	BBSTD3D45076	16.7				2	BBSTD3D45167
7.7				2	BBSTD3D45077	16.8				2	BBSTD3D45168
7.8				2	BBSTD3D45078	16.9				2	BBSTD3D45169
7.9				2	BBSTD3D45079	17				2	BBSTD3D45170
8				2	BBSTD3D45080	17.1	66	18	123	2	BBSTD3D45171
8.1	43	9	84	2	BBSTD3D45081	17.2				2	BBSTD3D45172
8.2				2	BBSTD3D45082	17.3				2	BBSTD3D45173
8.3				2	BBSTD3D45083	17.4				2	BBSTD3D45174
8.4				2	BBSTD3D45084	17.5				2	BBSTD3D45175
8.5				2	BBSTD3D45085	17.6				2	BBSTD3D45176
8.6				2	BBSTD3D45086	17.7				2	BBSTD3D45177
8.7				2	BBSTD3D45087	17.8				2	BBSTD3D45178
8.8				2	BBSTD3D45088	17.9				2	BBSTD3D45179
8.9				2	BBSTD3D45089	18				2	BBSTD3D45180
9				2	BBSTD3D45090	18.1	70	19	127	2	BBSTD3D45181
9.1	47	10	89	2	BBSTD3D45091	18.2				2	BBSTD3D45182
9.2				2	BBSTD3D45092	18.5				2	BBSTD3D45185
9.3				2	BBSTD3D45093	19				2	BBSTD3D45190
9.4				2	BBSTD3D45094	19				2	BBSTD3D45190
9.5				2	BBSTD3D45095	19.1	70	20	131	2	BBSTD3D45191
9.6				2	BBSTD3D45096	19.2					BBSTD3D45192
9.7				2	BBSTD3D45097	19.5					BBSTD3D45195
9.8				2	BBSTD3D45098	19.7					BBSTD3D45197
9.9				2	BBSTD3D45099	20					BBSTD3D45120
10				2	BBSTD3D45100	20					BBSTD3D45120
